Rich configuration options

  • Bigger tray T1(36 X 26cm)
  • Bigger tray T2 (40 X 30cm)
  • Right Armrest
  • Monitor Bracket
  • Button-type Headrest
  • Assistant Stool
Dental Unit S60

High-Quality Lighting.

Features 5 levels of brightness and 3 levels of color temperature adjustments.

Inner-track design: Start and stop smoothly, safe and comfortable.

The mobile cart treatment unit can be flexibly moved.

A New Generation of Electronic Control System

New simulating electronic control technology, 7-inch touch screen with powerful and diverse functions.

3 doctor programs meet the needs of personalized setting for multiple users.

The working status of dynamic instruments are displayed on touch screen graphically.

Intelligent linkage program by only one button to control cup filling, bowl rinsing, chair position and operating light on/off.

Anti-suction system of dynamic instrument reduces iatrogenic infection.

Instrument interlock: When one instrument is working, the others are locked safely to prevent accidental injuries and improve work efficiency.

Full-featured assistant element

© 12-level height adjustment of assistant elementPhotoelectric sensor system controlling on/off of HV suction/saliva ejector.

© 711 button touch control panel for assistant element can control chair position, operating light on/off, cup filling and spittoon rinsing.

Full-featured-assistant-element
s60
Multifunctional foot control

Pedal- type foot control and lever- type foot control is selectable.

Careful Consideration of Hygiene

BioTube Pro Disinfection System For Complete Water Lines

General Specification
Brand / Model Technology Color Temperature Intensity Light Spot Voltage Consumption
Siger V1 LED 4300k 8000 - 30000LUX 70 x 140 MM ( @ 700 MM ) 12-24 Vac 15VA
Siger V2 LED 5000k 8000 - 30000LUX 80 x 150 MM ( @ 700 MM ) 12-24 Vac 6VA
Siger V5 LED 3000 - 5500K 8000 - 35000LUX 90 x 200 MM ( @ 700 MM ) 12-24 Vac 18 VA
L500 LED 3300 - 4300K 30000 - 130000LUX F120 - 200 MM ( @ 1000 MM ) 12-24 Vac 25VA
Siger V1 LED 4300k 8000 - 30000LUX 70 x 140 MM ( @700MM ) 12-24 Vac 15VA
